Paramtents
Temperature -20℃-120℃
Speed ≦15m/s
Pressure ≦1.0MPA
Rotary Ring Material CAR/SIC/TC
Stationary Ring Material CER/SIC/TC
O-Ring Material VIT/NBR/EPDM
Spring & Metal Parts SUS304/SUS316
Application Clean Water,Sewage Water,Oil
Packging & Delivery
Min Order1 piece
Briefing
Detailed
Size/ Metric |
d | D3 | D1 | L2 | L1 | Size/ Inch | d |
D3
|
D1
|
L2
|
L1 |
560A-8
|
8 | 18.2 | 21 | 7 | 11.2 | 560A-3/8 | 9.52 |
23.5
|
22.22
|
6.4
|
22.2 |
560A-9
|
9 | 18.2 | 24 | 7 | 16.2 | 560A-1/2 | 12.7 |
26.0
|
25.40
|
6.4
|
22.2 |
560A-10
|
10 | 20.6 | 24 | 7 | 16.2 | 560A-5/8 | 15.8 |
30.0
|
31.75
|
8.7
|
23.8 |
560A-11
|
11 | 20.6 | 24 | 7 | 16.2 | 560A-3/4 | 19.1 |
32.5
|
34.92
|
8.7
|
23.8 |
560A-12
|
12 | 21.8 | 26 | 7 | 17.2 | 560A-7/8 | 22.2 |
38.5
|
38.10
|
8.7
|
25.4 |
560A-13
|
13 | 21.9 | 26 | 7 | 17.2 | 560A-1 | 25.4 |
44.0
|
41.27
|
9.5
|
27.0 |
560A-14
|
14 | 26.4 | 28 | 7 | 18.2 | 560A-1-1/8 | 28.6 |
48.0
|
44.45
|
9.5
|
28.6 |
560A-15
|
15 | 26.4 | 28 | 7 | 18.2 | 560A-1-1/4 | 31.7 |
50.0
|
47.62
|
9.5
|
28.6 |
560A-16
|
16 | 26.4 | 32 | 8 | 19.2 | 560A-1-3/8 | 34.9 |
54.5
|
50.80
|
9.5
|
30.2 |
560A-17
|
17 | 29.5 | 32 | 8 | 19.2 | 560A-1-1/2 | 38.1 |
58.5
|
53.97
|
9.5
|
30.2 |
560A-18
|
18 | 29.5 | 35 | 8 | 19.2 | 560A-1-5/8 | 41.2 |
64.0
|
60.32
|
11.1
|
36.5 |
560A-19
|
19 | 29.5 | 35 | 8 | 19.2 | 560A-1-3/4 | 44.4 |
67.0
|
63.50
|
11.1
|
36.5 |
560A-20
|
20 | 25 | 38 | 8 | 20.2 | 560A-1-7/8 | 47.6 |
71.0
|
66.67
|
11.1
|
39.7 |
560A-22 | 22 | 31.6 | 40 | 8 | 20.2 | 560A-2 | 50.8 | 73.5 | 69.85 | 11.1 | 39.7 |
560A-25 | 25 | 33.6 | 44 | 9 | 20.2 | ||||||
560A-28 | 28 | 39.6 | 46 | 9 | 21.2 | ||||||
560A-30 | 30 | 45.0 | 50 | 9 | 22.2 | ||||||
560A-32 | 32 | 46.6 | 54 | 9 | 24.2 | ||||||
560A-35 | 35 | 46.6 | 58 | 10 | 26.2 | ||||||
560A-38 | 38 | 50.8 | 60 | 10 | 27.2 | ||||||
560A-40 | 40 | 54.3 | 64 | 10 | 28.2 | ||||||
560A-45 | 45 | 61.3 | 66 | 10 | 30.2 | ||||||
560A-50 | 50 | 67.8 | 72 | 10 | 32.2 |
